Brand, Model and Release Date
Information about the brand, model release date.
| Manufacturer | Pioneer |
| Model | S-CN301-LR |
| Release Date | 2015 |
| HifiSpecs Rating | - |
| Amazon Rating | |
| Price |
Technical Specs
Technical characteristics of the speakers.
| Amplification Type | Passive |
| Crossover Type | 2-Way |
| Enclosure type | Bass Reflex |
| Frequency Range (+/-3 dB)[Hz] | 45 - 40000 |
| Frequency Range (-6dB)[Hz] | - |
| Maximum SPL [dB] | - |
| Sensitivity (2,83 V/1 m)[dB] | 90 |
| Nominal Impedance (Ohms) | 6 |
| THD (Total Harmonic Distortion) | - |
| Recommended Amplifier Power [W] | - |
| Crossover Frequency [Hz] | - |
| Bass Reflex Tuning Frequency [Hz] | - |
| Driver Units | Tweeter: 2 cm dome tweeter |
| Connectivity | Wired |
| Inputs | Single Wire |
| Outputs | - |
| Magnetic Shielding | No |
Placements and Distances
Where and how to put them.
| Form Factor | Shelf, Stand |
| Distance from Wall [cm] | 15 |
Dimensions and Weight
Speaker dimensions and weight without stands.
| Length | ~5.31 in ~134.87 mm ~13.49 cm |
| Width | ~8.66 in ~219.96 mm ~22 cm |
| Height | ~9.05 in ~229.87 mm ~22.99 cm |
| Weight | ~6.39 lb ~2898.46 g ~2.9 kg |
| Shipping Weight | ~14.9 lb ~6758.53 g ~6.76 kg |
Colors and Accessories
List of available colors and optional accessories.
| Colors |
|
| Accessories | – |
| Detachable Grilles | No |
Price and Warranty
Satisfaction is (not) guaranteed.
| Warranty | 3 Years |
| Manufacturer URL | https://www.pioneer-audiovisual.eu/eu |
| Amazon |
